Figures 5.2.2-1 and 5.2.2-2 The following figured show the Charts sub-tab panel of the Current value tab displayed by lane and by direction, respectively (depending on the system setup). Figure 5.2.2-1 The Charts sub-tab of the Current value tab displayed by lane
Figure 5.2.2-2 The Charts sub-tab of the Current value tab displayed by direction
Table 5.2.2-1
Displaying by lanes:
Displaying by direction:
The following table describes the elements of the Charts sub-tab.
Table 5.2.2-1 The elements of the Charts sub-tab of the Current value tab
panel.
Element | Description |
|---|---|
| The Traffic Detector name |
| The lane number or direction |
| Total number of vehicles registered for the lane (direction) |
| Indication of a traffic jam in the lane (direction) |
| Chart showing the number of vehicles in the lane (direction) |
| Chart showing the road load of the lane (direction), % |
| Chart showing the statistics for the average speed of different vehicles types |
