Use of Axxon One through a web client takes place remotely, through a web browser and the TCP/IP protocol. Remote video surveillance via a web browser does not require installation of Axxon One.

...

1. Start a web browser.

2. In the address bar, type the address of the Axxon One server Server in the following format: <web server IP address>:<Port>/<Prefix>.

   Tip
   Connecting the Web and Mobile Clients to the Server behind NAT




   Note
   title Attention!
   The Server URL is case-sensitive. You have to type in the URL using the exact case of characters specified in settings(see Configuring the Web server).

   Image Added

   Note
   title Attention!
   If the web server is properly configured (see Configuring the Web server), then a secure HTPPS connection is automatically established.




3. Enter a user name username and password for connecting to the Axxon One web server Web Server.
   Image Modified

   Note
   title Attention!
   After 5 successive failed authorization attempts, the user is blocked for 10 minutes.




This will show the  web the Web-client interface. By default, the first listed layout will be displayed. If there are no layouts, the Cameras panel opens on the left and shows the video from the first listed video camera.
Image Added

To switch between users, press the Change User link in the upper-right corner; another authentication will follow.

Image RemovedImage Added
