The DNS section is used for setting
...
up automatic
...
connections between the
...
client and
...
backup video
...
servers in case of a connection loss with the main
...
server. In
...
the DNS section, it is necessary to specify network names and IP addresses of
...
the backup video
...
servers, as they
...
aren't listed in the Windows registry by default.
The settings panel of the the DNS section is shown in the figure.
The table describes the setting parameters of the settings panel of the the DNS section are described in the table.
№ | Parameter name | Method for setting the parameter value | Parameter description | Representation | Default value | Value range |
1 | System identifier | Enter the value in the field | Sets the network name of the |
backup video |
server if the connection with the main |
server is lost |
NA |
NA | Depends on the network settings of the |
backup video |
server | ||
2 | IP address | Enter the value in the field |
Sets the IP address of the selected |
backup video |
server | IP address |
NA | Depends on the network settings of the |
backup video |
server | |||
3 | Allow all names | Click the button | Automatically adds the computers IP addresses, set in the System identifier column, to the IP address column if these IP addresses are enabled and identified |
NA |
NA |
NA |
| Info | ||
|---|---|---|
| ||
To delete a specified server, select it in the list (click the row) and press Ctrl+Del on the keyboard. |
...
