Configure IntelliVision LPR module as follows:

1. Go to the settings of the  IntelliVision LPR object created under the LPR channel object.

2. Specify the LPR channel (1) where the IntelliVision LPR module is to operate.

3. Set the Use GPU (2) checkbox checked if GPU computing resources are to be in use for better LPR performance.

   By default CPU recources only are in use.




4. Select the LPR accuracy in the Accuracy (3) dropdown list. The following options are available:

   1. Maximum - enables maximum recognition accuracy, but it causes great CPU and/or GPU load.
   2. High - enables high recognition accuracy, it requires less computing resources than for maximum accuracy.
   3. Fast - enables high recognition speed, but the accuracy becomes worse.
5. Select the computing resources use mode in the Strategy (4) dropdown list. The following options are available:
   1. Process  - mild mode: no more than 1 core for 1 license plate.
   2. System - default mode: all available computing cores are in use;
   3. Core  - strict mode: 1 core per stream.
6. Specify the minimum time interval lasting between frames processings for the Interval (5) parameter (i.e. all frames within this interval won't be processed).
7. Select the profile of country license plates that are to be recognized in the Profile (6) dropdown list. The following options are available:

   1. 0 - China and African countries.
   2. 3 - USA, Russia, Taiwan and African countries.
   3. 6 - USA, Russia, Taiwan, Canada, India, Sri Lanka, Australia and European countries.

   4. 9 - USA.

      "9" profile enables recognizing correctly USA license plates with vertical letters on the plates. It can also be recommended to be in use when maximum recognition accuracy is needed if there is no high load on hardware.




      Greater profile number enables more accurate LPR comparing to the solution with smaller number, but it is more demanding to computing resources.




8. Click Apply (7).

Configuration of the IntelliVision LPR module is completed.
