Web Board allows users to view a selected Web page in the tile.

To configure Web Board:

1. Add an information board to the layout (see Adding information boards to cells).

2. In the upper-right corner, click the button.

3. To allow operators to hide the information board, select the Allow hiding panel check box (1).


4. Select the web page output: Internet Explorer or Gecko (2).

5. Enter the address in the URL field (3).

   The URL field supports addresses in the following formats: http://www.site.com http://site.com https://www.site.com https://site.com www.site.com site.com [IP-address] [IP-address]:[Port] http://[IP-address] http://[IP-address]:[Port]




6. Click the Apply button to save changes (4).

Configuration of the Web Board is complete.
