Access direction can be given in the Add. info field of the Event Viewer when an alarm is displayed.

Note

See Features of Nedap retail events viewing for a detailed description of possible events and additional info for them.

See Intellect software. Operator’s Guide for a description of the Event Viewer interface. The most relevant version of this document is available in the AxxonSoft documentation repository.

This feature is disabled by default. To enable it, do the following:

  1. Go to the Nedap retail object settings panel.
  2. Set the Display access direction checkbox (3).
  3. Click Apply (2)

Configuration of displaying of access direction is completed.
