Editing a layout is done by creating a new layout based on one that has been already created and modified in terms of the quantity, content, and position of viewing tiles.

To create a new layout based on a previously created one, switch to the desired layout, bring up the layout ribbon context menu in the video surveillance monitor, then click  and select Save layout.

A new layout will now be created.

The number of viewing tiles in a layout can be modified by increasing the size of one or more viewing tiles using the increase/decrease buttons in the viewing tile (1) and then clicking the Set button (2).

The Set button is made available once the size of the viewing tile is increased. Clicking the Set button sets the current size of the viewing tile. Once the size of the viewing tile is set, you cannot reduce the size of the viewing tile.

To save the position of video cameras in the layout, select Save layout in the context menu.
