Documentation for Axxon Next 3.1.1. Documentation for other versions of Axxon Next is [available too].

The system log is a log containing system information on events, including system error entries.

The system log is stored in a local database for each server. You can set access to the system log for a user group in the Permissions tab under Settings (see the section titled The Role object).

To configure storage of the archive, system log, and metadata:

  1. Go to Settings → Options → User interface (1–2).
  2. In the Period field, enter the amount of days to store the system log in the Server’s database and to store metadata in the object trajectory database (3).

  3. In the appropriate field, enter the amount of hours after which outdated events will be purged from the system log (4).

    Outdated events are events that have been stored in the system log for a period greater than that indicated in step 2.

    Note

    Every 12 hours after Axxon Next is started, the object trajectory database is purged of video recordings that have been stored for more than the specified storage period

  4. If you want to limit the archive capacity, select the corresponding check box and specify the archive capacityin days (5). If a limit is set, only video within the specified time frame will be available in the archive. Recordings that exceed the specified archive capacity will only be hidden; they will not be deleted.

  5. Click the Apply button.

Configuration of the system log is now complete.
